Specifications
Mechanical
Dimensions
Ø197 x 35 mm
Weight
Without Mount: 460 g
With Mount: 600 g
Enclosure Material
Plastic
Mount material
SGCC Steel
Weatherproofing
IP54
Hardware
Management Interfaces
Ethernet
Bluetooth
Networking Interface
(1) GbE RJ45 port
Buttons
Factory Reset
LEDs
White/Blue
Power Method
802.3at PoE+
Power Supply
UniFi PoE switch
48V, 0.5A PoE adapter (optional)
Supported Voltage Range
44 to 57VDC
Max. Power Consumption
13W
Max. TX Power
2.4GHz
5GHz

22 dBm
26 dBm
MIMO
2.4GHz
5GHz

2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
Throughput Speeds
2.4GHz
5GHz

573.5 Mbps
4.8 Gbps
Antenna Gain
2.4GHz
5GHz

4 dBi
6 dBi
Mounting
Wall/ceiling (included)
Operating Temperature
-30 to 60° C (-22 to 140° F)
Operating Humidity
5 - 95% Noncondensing
Certifications
CE, FCC, IC
Software
Wi-Fi Standards
802.11a/b/g
Wi-Fi 4/Wi-Fi 5/Wi-Fi 6
Wireless Security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
8 per Radio
VLAN
802.1Q
Advanced QoS
Per-User Rate Limiting
Guest Traffic Isolation
Supported
Concurrent Clients
300+
Zero wait DFS
Yes*
*Supported with upcoming firmware versions.
Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (Wi-Fi 4)
6.5 Mbps to 600 Mbps
(MCS0 - MCS31, HT 20/40)
802.11ac (Wi-Fi 5)
6.5 Mbps to 3.4 Gbps
(MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (Wi-Fi 6)
7.3 Mbps to 4.8 Gbps
(MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
